FDUA Ducted Series (High Static Pressure)FDUA200AVSAVG

Ducted Systems - FDUA Ducted Series (High Static Pressure)


AUD $6,704.72

  • Three Phase model
  • Automatic operation mode
  • Weekly /Sleep timer
  • Silent operation
  • Wired and wireless control options
Indoor FDUA200VG
Outdoor FDCA200VSA
Power supply Outdoor Unit   3 Phase 415V 50Hz
CapacityØ Cooling T1 kW 20.0 (6.9-28.0)
Heating H1 22.4(5.5-31.5)
InputØ Cooling T1 kW 6.03
Heating H1 5.5
EER Cooling T1   3.32
COP Heating H1 4.07
Sound pressure level (JIS C9612)Ø Indoor dB (A) P-Hi:52 Hi:50 Me:47 Lo:45
Outdoor 59
Sound power level (JIS C9612) Outdoor dB(A) 73
Airflow Indoor l/s P-Hi:1333 Hi:1200 Me:1067 Lo:933
External static pressure   Pa 200
External dimensions (HXWXD) Indoor mm 379x1600x893
Outdoor 1505x970x370
Net weight Indoor kg 89
Outdoor 143
Refrigerant piping Liquid line mm Ø12.7
Gas line Ø22.22 , Ø25.4 or Ø28.58
Connection method   Liquid: Flare / Gas: Brazing
Refrigerant R410A Quantity kg 7.2
Pre charged to pipe length m 30
Maximum pipe length m 70*
Supply air connection mm 250x1450
Return air connection mm 250x1450
Controller   RC-E5, RC-EX3 or RCN-KIT4-E2
Safety pan   NA
* Refer to technical manual
